Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Bottled water filling

Good products of course need high quality, reasonable equipment to ensure product quality. To build the skill rakhine To provide customers with the international advanced level of the whole plant equipment and technology, to provide perfect after-sales service: the use of products and technology set the advantages of the world's excellent equipment in one, and build technology Jianbang's own technical strength and scale, to ensure that every machine provided can get good service, to ensure that both domestic machines and imported machines have sufficient inventory. The design of bottled water can ensure long-term stable and reliable operation of users in the future large-scale and continuous production, and ensure product quality from the aspects of hardware and software. Features are as follows: Lightweight bottle packaging is in line with the theme of a global low-carbon economy. Compared with the traditional beverage equipment, the lightweight blowing, filling and spinning integrated equipment has the advantages of high efficiency, low cost and low energy consumption. It will be the development trend of food packaging machinery industry to replace the traditional blowing, filling and capping stand-alone production process by the blowing, filling and spinning integrated machine.1Comprehensively reduce the gram weight of bottle blank;2Reduce the thickness of the bottle wall;3Optimize the bottle blank heating system;4Develop new bottle clamping device and filling valve to realize the filling of light weight bottle;5Adopt new cover management system, with detection device, with automatic elimination function. To build the skill rakhine Fully automatic rotary blowing bottle/filling/Screw cap all-in-one machine, using well-known components at home and abroad to ensure the excellent quality of the whole machine; Adopt the most advanced foreign design concept, high speed and efficiency, high product consistency, high output, fast speed, high yield, stable operation, low maintenance cost, is high-endPETThe first choice in the beverage industry.

inquiry
  • Product details
Technical parameters Technical parameters
Filling quotas 16-80 capacity 6000-36000BPH
Filling range 0.3L-5L Filling level accuracy ±3mm
The engine power Air pressure 0.6-0.8MPa
Gas consumption 600-900NL/MIN Height of operating surface 1500±50mm
Machine size (length*wide*High) The material 304
Electrical configuration Electrical configuration
PLC Siemens Touch screen Siemens
Pneumatic components SMC The circuit breaker Schneider of France
The inverter Danfoss, Denmark Photoelectric sensor Germany Lloyd test
Switch power supply, button, alarm light Schneider of France
Product features Product features
  • Simple structure

    Simple structure

    Mechanical valve negative pressure filling, simple structure, filling speed.

  • High quality material

    High quality material

    The filling valve and its assembly consist of304Made of high quality stainless steel, very high finish, easy to discharge and barrier-free laminar flow.

  • Automatic stabilization

    Automatic stabilization

    The material cylinder is equipped with a liquid level sensor, which can automatically stabilize the liquid level in the material cylinder by controlling the regulating valve on the material feeding pipe.

  • Ensure the quality

    Ensure the quality

    The cylinder, filling valve and other parts in contact with the material are used304High quality stainless steel to ensure product quality.

  • Stable and reliable

    Stable and reliable

    The base of the equipment is made of carbon steel with high quality external application304Stainless steel, integral welding processing, with enough rigidity and ensure processing assembly accuracy and machine movement stability.

  • The transmission system

    The transmission system

    The combination of reducer motor and open gear drive has the advantages of simple structure, stable operation and convenient maintenance.

  • Overload protection

    Overload protection

    Bottle feeding system is composed of bottle feeding screw and star wheel guard plate. The lower part of star wheel is equipped with overload protection device to prevent the equipment parts from being damaged when the bottle is overloaded.

  • Maintenance is convenient

    Maintenance is convenient

    Equipped with centralized lubrication system, convenient maintenance.

Product advantage Product advantages
Reduce artificial

High filling precision

Can reduce material loss for customers, reduce production costs;

To save space

Reduce artificial

Mechanical replacement of labor while reducing the intensity of personnel work, effectively solve the problem of difficult recruitment of enterprises;

To ensure the quality

To ensure the quality

Fully closed filling environment, reduce material and external contact, avoid foreign matter, ensure product quality and safety.

Promote efficiency

Promote efficiency

Fast filling speed, high production efficiency.
